HP-F1 series with sliding beam Four-column hydraulic press is traditional mode hydraulic, structure is reasonable is reasonable, it is suitable to large industrial enterprises with thick, durable design philosophy.
Technical specification
|
model |
units |
HP-100F1 |
HP-150F1 |
HP-200F1 |
HP-250F1 |
HP-315F1 |
HP-500F |
|
capacity |
kn |
1000 |
1500 |
2000 |
2500 |
3150 |
5000 |
|
pressure |
Mpa |
31.5 |
31.5 |
31.5 |
31.5 |
32 |
32 |
|
travel |
mm |
300 |
300 |
300 |
300 |
400 |
500 |
|
Table size |
mm |
860*560 630*560 |
870*670 670*645 |
970*700 700*700 |
1090*800 800*800 |
1090*800 800*800 |
1640*1200 1200*1400 |
|
dimension |
mm |
700*1000*1900 1100*700*1150 |
800*1000*2100 1100*700*1200 |
800*1000*2200 1100*700*1200 |
1300*1000*2200 1100*700*1300 |
1300*1000*2200 1100*800*1500 |
1600*1350*2950 1400*800*1500 |
|
weight |
kg |
2200 |
2600 |
3100 |
4200 |
4600 |
9600 |
